Choosing Design Software

Every Speedster strives for "THE LOOK"....that simple, classic, fast, sleek, always in motion, vintage, stance.

Most Speedsters are not Designed,  they are Shaped during construction.  OK if you are Artistic and have a good eye.  I'm not Artistic. I don't have the Eye. And I chose to build my speedster body with wooden strips.  The strips confine the shape. Where their parallel lines run has a lot to do with "the Look".     I needed the computer to get simplicity... to get the Look.

 I chose Rhino as the design software.

The decision was not easy.  I knew the the speedster body was basically an upside down boat.  The shape was freeform... Too complex for many CAD packages.

I looked at Marine design software. -- AeroHydro, Surface Works, and Prolines.

I tried engineering software : AutoCad, ProEngineer, and CATIA.

I tried Alias/Wavefront-Maya which Hollywood uses for animations and special effects.

All this software could do the job. I used the current release Oct 1, 2002 except for AutoCad where I used AutoCad-2000

The big differences are Ease of learning & Use, Curve Analysis and control, Rendering, and ability to generate CNC code natively to cut the stations for the form on a CNC router vs exporting to other software like MasterCam (MC).... sometimes through CAD software like Rhino/ProEngineer/AutoCad -- Rhino has an interlink directly to MasterCam(MC).



It boiled down to 3 leading packages with different strengths :
    Maya for shape and rendering
    Pro/E for ease of getting CNC code
    Rhino for Ease of Use

I liked Rhino.  The Rhino Marine Design Tutorial was very good.

Looking back, I think Rhino was definitely the right choice.

I spent weeks making this choice.
